AGM隔板
項目名稱(chēng) | 單位 | 國家標準 | 企業(yè)標準 | |||
---|---|---|---|---|---|---|
厚度(d) | 10Kpa | mm | ±8% | ±8% | ||
20Kpa | ±8% | ±8% | ||||
100Kpa | ±5% | ±3% | ||||
定量(G) | 10Kpa | g/㎡.mm | ≥130 | 135-150 | ||
抗張強度(P) | KN/m | 厚度(10Kpa) | 指標 | 厚度(100KPa) | 指標 | |
≤2.0 | ≥0.42d | ≤1.0 | ≥0.75d | |||
≥2.0 | ≥0.84d | ≥1.0 | ||||
毛細吸酸高度(H) | mm/1min | *≥30 | ||||
mm/2min | *≥60 | |||||
mm/5min | ≥75 | ≥90 | ||||
mm/24h | *≥620 | |||||
孔徑¢ | um | ≤22 | ≤18 | |||
加壓吸酸值(W) | g/g | ≥5.5 | ≥5.5 | |||
孔率(A) | % | ≥90 | ≥92 | |||
電阻(∩) | ∩ | ≤0.0005 | ≤0.0005 | |||
水份 | % | ≤1.0 | ≤0.5 | |||
浸酸失重(L) | % | ≤3.0 | ≤2.0 | |||
鐵含量(Fe) | % | ≤0.005 | ≤0.003 | |||
氯含量(Cl) | % | ≤0.003 | ≤0.002 | |||
還原高錳酸鉀物質(zhì) | ml/g | ≤5.0 | ≤2.5 |
